HRS Ferritic · Hastelloy C22 Plate Supplier, Stockist & Importer
Hastelloy C22 Nickel Alloy Plates
Alloy C22 Plates
Excellent Resistance to Oxidizing & Reducing Environments · Superior Protection Against Pitting & Crevice Corrosion · High Resistance to Stress Corrosion Cracking · Global Industrial Supply
ASTM B575 / UNS N06022
DIN 2.4602
EN NiCr21Mo14W
JIS NW 6022
📋 Table of Contents
HRS Ferritic · Trusted Global Supplier
What is Hastelloy C22 Plate?
Hastelloy C22 Plate is a versatile nickel-chromium-molybdenum alloy known for its outstanding resistance to a wide range of corrosive environments. It performs exceptionally well in both oxidizing and reducing conditions and offers superior protection against pitting, crevice corrosion, and stress corrosion cracking. Hastelloy C22 Plates are widely used in industries where reliability and corrosion resistance are critical.
- Excellent resistance to oxidizing and reducing environments
- Superior protection against pitting and crevice corrosion
- High resistance to stress corrosion cracking
- Long service life with minimal maintenance
- Suitable for highly aggressive chemical applications
- Good weldability and fabrication properties
- Reliable performance under extreme conditions
HighCorrosion Res.
Working Mechanism
How Hastelloy C22 Plate Works
Hastelloy C22 Plate works by forming a stable and protective oxide layer on its surface when exposed to aggressive chemical environments. This passive layer prevents further oxidation and corrosion, ensuring long-term durability even under extreme conditions. Chromium plays a vital role in enhancing oxidation resistance, while molybdenum provides resistance against localized corrosion such as pitting.
20-22.5%
Chromium Content
12.5-14.5%
Molybdenum Content
690-900
Tensile MPa
0.5-100
Thickness (mm)
Composition Analysis
Metallurgical Characteristics of Hastelloy C22 Plate
Key alloying elements that contribute to the high-performance corrosion-resistant structure of Alloy C22.
Ni
Nickel
Provides excellent corrosion resistance and stability in aggressive environments.
Cr
Chromium
Enhances oxidation resistance and contributes to the passive protective layer.
Mo
Molybdenum
Improves resistance to pitting and crevice corrosion in chloride environments.
Fe
Iron
Adds structural strength while maintaining the alloy's versatility.
W
Tungsten
Boosts resistance to localized corrosion and enhances overall durability.
C
Carbon
Contributes to the strength and hardness of the Hastelloy plate.
P
Phosphorus
Controlled levels to maintain high-performance corrosion resistance.
S
Sulfur
Carefully limited to ensure optimal material integrity and fabrication.
Technical Data
Specifications for Hastelloy C22 Plate
ASTM B575 · ASME SB575 · UNS N06022 · EN 2.4602 / NiCr21Mo14W
| Specification | Details |
|---|---|
| ASTM / ASME | ASTM B575 / ASME SB575 (Plate, Sheet, and Strip) |
| UNS | UNS N06022 |
| EN | 2.4602 / NiCr21Mo14W |
| DIN | 2.4602 / NiCr21Mo14W |
| ISO | NW 6022 |
| JIS | NW 6022 |
| Product Form | Sheets / Plates |
| Thickness Range | 0.5 mm to 100 mm |
| Standard Widths | 1000, 1219, 1250, 1500, 1800, 2000, 2500, 3000, 3500 mm, etc |
| Standard Lengths | 2000, 2440, 2500, 3000, 5800, 6000 mm, etc |
| Surface Finish | Hot Rolled (HR), Cold Rolled (CR), Annealed & Pickled (AP) |
| Supply Condition | Solution Annealed |
| Cutting Methods | Plasma, Laser, Waterjet, Oxy Propane |
| Packaging | Bundled, Wooden Plates, Bubble wraps, Customized |
Inventory
Available Stock & Product Forms
Flat Products
Precision sheets, heavy plates, and shim sheets available in various grades.
Coils & Strips
Slitting coils, perforated coils, and thin foils from 0.05 mm thickness.
Specialty Forms
Circles, rings, and custom-cut blanks tailored to your specifications.
Edge Types
Mill edge, slit edge, round edge, and square edge conditions available.
Chromium (Cr)
20.0–22.5% — Enhances oxidation resistance and passivity.
Molybdenum (Mo)
12.5–14.5% — Resists pitting and crevice corrosion.
Nickel (Ni)
Balance — Base element for superior corrosion resistance.
Tungsten (W)
2.5–3.5% — Boosts resistance to localized corrosive attack.
Tensile Strength
690–900 MPa — High strength for extreme pressure environments.
Yield Strength
≥ 310 MPa — Reliable load-bearing capacity for critical parts.
Elongation
≥ 45% — Superior ductility for complex fabrication.
Hardness
≤ 100 HRB — Optimal hardness for industrial durability.
Product Range
Types of Hastelloy C22 Plate
Available in multiple finishes and conditions for diverse engineering needs.
Hastelloy C22 Hot Rolled Plate
Hastelloy C22 Cold Rolled Plate
Hastelloy C22 Polished Plate
Hastelloy C22 Industrial Plate
Custom Cut Hastelloy C22 Plate
Annealed & Pickled Hastelloy C22 Plate
Application Sectors
Industries We Serve
Sugar Industry
Global cane and beet processing requiring thermal endurance.
Power Industry
Electricity generation and distribution systems.
Ship Building
Marine propulsion and exhaust components.
Mechanical & Plant Engineering
Industrial machinery design solutions.
Food, Beverage & Dairy
Processed food manufacturing environments.
Oil & Gas Plant
Refinery furnace units and burner assemblies.
Chemical Composition
Chemical Details of Hastelloy C22 Plate
Typical composition ranges for high-performance Alloy C22 nickel plates.
| Element | Composition (%) |
|---|---|
| Nickel (Ni) | Balance |
| Chromium (Cr) | 20.0 – 22.5 |
| Molybdenum (Mo) | 12.5 – 14.5 |
| Iron (Fe) | 2.0 – 6.0 |
| Tungsten (W) | 2.5 – 3.5 |
| Cobalt (Co) | ≤ 2.5 |
| Manganese (Mn) | ≤ 0.50 |
| Vanadium (V) | ≤ 0.35 |
| Silicon (Si) | ≤ 0.08 |
| Phosphorus (P) | ≤ 0.02 |
| Sulfur (S) | ≤ 0.02 |
| Carbon (C) | ≤ 0.015 |
Performance Data
Mechanical Properties of Hastelloy C22 Plate
690–900
Tensile Strength
MPa — Ultimate Tensile Strength for extreme durability
≥ 310
Yield Strength
MPa — 0.2% Offset Yield Strength for reliability
≥ 45%
Elongation
Superior ductility for fabrication and extreme forming
≤ 100 HRB
Hardness
Rockwell B Hardness for industrial toughness
206 GPa
Elastic Modulus
Consistent structural stiffness under heavy loads
8.69 g/cm³
Density
Density of the high-performance nickel-based alloy
Cost Information
Price List for Hastelloy C22 Plate
Price Factors
What affects the Hastelloy C22 price?
- Fluctuations in nickel and molybdenum costs
- Plate size, thickness, and dimensions
- Surface finish and customization requirements
- Supply chain, logistics, and import costs
- Market demand and industrial availability
- Custom cutting and fabrication readiness
Get Pricing Today
Get A Quote!
Competitive rates · High quality · Global delivery
📧 [email protected]
International Standards
Equivalent Grades for Hastelloy C22 Plate
Cross-reference table for international designations of Alloy C22 plates.
| Standard / System | Equivalent Grade / Designation |
|---|---|
| UNS | N06022 |
| ASTM / ASME | B575 / SB575 |
| DIN / Werkstoff | 2.4602 |
| EN (European) | 2.4602 / NiCr21Mo14W |
| JIS (Japan) | NW 6022 |
| ISO | NW 6022 |
| GOST (Russia) | ХН60МВ |
| BS (British Standard) | NA 57 |
| NACE Compliance | MR0175 / ISO 15156 |
| Trade Name | Hastelloy® C22 / Alloy C22 |
📦
Ready Stock Availability
- Flat Products: Precision sheets, heavy plates, shim sheets
- Coils & Strips: Slitting coils, perforated coils, thin foils from 0.05 mm
- Speciality Forms: Circles, rings, custom-cut blanks, chequered plates
- Edge Conditions: Mill edge, slit edge, round edge, square edge
🏭
Quality & Logistics
- Testing: PMI, Ultrasonic (UT), Radiography (RT), corrosion testing
- Certification: EN 10204 3.1 / 3.2, NACE compliance on request
- Global Logistics: Supplying USA, UAE, Saudi Arabia, Singapore, Europe
- Export Grade: ISPM-15 fumigated wooden crates, moisture-protected packaging
Use Cases
Applications of Hastelloy C22 Plate
✈️ Aerospace
Used in aerospace components where high resistance to temperature and corrosion is essential.
⛽ Oil & Gas
Widely used in pipelines, offshore equipment, and refineries exposed to harsh environments.
🌾 Fertilizer Industry
Suitable for handling aggressive chemicals used in modern fertilizer production.
⚡ Electric & EV
Used in battery systems and electrical components requiring high durability.
🏗️ Construction
Applied in structures exposed to extreme environmental conditions for long-term performance.
🧪 Chemical Processing
Extensively used in reactors, heat exchangers, and storage tanks for corrosives.
🚗 Automotive
Applied in exhaust systems and various high-temperature structural components.
💊 Pharmaceuticals
Ensures corrosion-resistant and contamination-free production environments.
Why HRS Ferritic
Why Choose HRS Ferritic for Hastelloy C22 Plates?
HRS Ferritic is a leading Hastelloy C22 Plate Supplier and Stockist committed to delivering excellence with reliability and trust. We source premium materials from certified global manufacturers, ensuring consistent quality, competitive pricing, and bulk availability for critical industrial projects worldwide.
Leading Hastelloy C22 Plate Supplier & Stockist
Premium quality products from certified global mills
Wide range of sizes and custom specifications
Competitive pricing and bulk inventory availability
Fast delivery and expert global export services
EN 10204 3.1 / 3.2 quality documentation
Dedicated customer technical support
Supplying to over 20+ countries worldwide
🇮🇳
Cities We Supply In India
New Delhi · Ahmedabad · Jaipur · Surat · Salem · Gandhinagar · Varanasi · Haldia ·
Bhiwandi · Tiruppur · Jamnagar · Thiruvananthapuram · Rajahmundry · Visakhapatnam · Bhubaneswar ·
Vijaywada · Rajkot · Bharuch · Coimbatore · Nagpur · Raipur · Cochin · Ludhiana · Panipat · Durgapur ·
Agra · Indore · Kuala Lumpur · Al Jubail · Pimpri-Chinchwad · Sharjah · Karachi · Chandigarh · Bogota · Muscat · Madrid · Tehran · Granada · Jakarta · Los Angeles · Rio de Janeiro · Melbourne · Cairo · New York · Busan · Milan · Montreal · Singapore · Sydney · Dubai · Lagos · Gurgaon · Port-of-Spain · Hong Kong · Navi Mumbai · Secunderabad · Bangkok · Aberdeen · Bhopal · Atyrau · Caracas · Jamshedpur · Thane · Faridabad · Ahvaz · Ahmedabad · Hanoi · Bengaluru · Dallas · Moscow · Surat · Riyadh · Rajkot · Al Khobar · Hyderabad · Haryana · Ernakulam · Gimhae-si · Algiers · Thiruvananthapuram · Brisbane · Calgary · Mumbai · Chennai · Courbevoie · Toronto · Vung Tau · Ankara · Doha · Nagpur · Howrah · Ranchi · Perth · Noida · Houston · Kolkata · Chiyoda · Mexico City · Edmonton. Geoje-si · Abu Dhabi · Santiago · New Delhi · Colombo · Ludhiana · Lahore · Coimbatore · Ho Chi Minh City · Manama · Ulsan · London · Visakhapatnam · Jaipur · Kuwait City · Seoul · Istanbul · Pune · Baroda · Kanpur · La Victoria · Jeddah · Dammam · Petaling Jaya · Nashik · Vadodara ·jamnagar ·hazira · jubail industrial city · Ajman · Capetown · San Francisco · sao paulo · Barcelona · Ahmedi · Muscat · Madrid · Birmingham · Johannesburg.
🌍
Countries We Export To
Saudi Arabia · Qatar · Canada · Sri Lanka · Iran · Nigeria · Bangladesh · Oman · UAE ·
Turkey · Kuwait · Venezuela · Africa · Singapore · Netherlands · United Kingdom · Mexico · Malaysia ·
United States · Australia · Japan Saudi Arabia · Iran · Iraq · UAE · Qatar · Bahrain · Oman · Kuwait · Turkey · Yemen · Syria · Jordan · Cyprus · Nigeria · Algeria · Angola · South Africa · Libya · Egypt · Sudan · Equatorial Guinea · The Republic Of Congo · Gabon · USA · Canada · Mexico · Panama · Costa Rica · Puerto Rica · Trinidad And Tobago · Jamaica · Bahamas · Denmark · Russia · Norway · Germany · France · Italy · Uk · Spain · Ukraine · Netherland · Belgium · Greece · Czech Republic · Portugal · Hungary · Albania · Austria · Switzerland · Slovakia · Finland · Ireland · Croatia · Slovenia · Malta · India · Singapore · Malaysia · Indonesia · Thailand · Vietnam · South Korea · Japan · Sri Lanka · Maldives · Bangladesh · Myanmar · Taiwan · Cambodia · Argentina · Bolivia · Brazil · Chile · Venezuela · Colombia · Ecuador · Guyana · Paraguay · Uruguay · New Zealand · Romania · Puerto Rico · Nepal · Kenya · Afghanistan · Lithuania · Belarus · Zimbabwe · Israel · Azerbaijan · Poland · Australia · Morocco · Philippines.
Support
Frequently Asked Questions
Quick answers to common queries about Hastelloy C22 Plates.
Yes, bigger plates naturally cost more since they use more nickel-alloy material and require extra handling and transportation.
Thicker Hastelloy C22 plates are pricier because they need more alloy, longer rolling, and higher energy during manufacturing.
Absolutely—smooth, polished, or pickled finishes add extra processing steps, which slightly raise the cost.
Since nickel, molybdenum, and chromium are key ingredients, any market fluctuation directly affects the plate’s cost.
Yes, tailor-made plates involve extra cutting, more scrap, and special production setups, which all add to the price.
Hastelloy C22 plates used in chemical plants, marine environments, or corrosive conditions often cost more due to tighter quality standards and testing.
Yes, NACE compliance, third-party inspection, and documentation add to the overall cost but ensure reliability in critical applications.
