HRS Ferritic · Incoloy 800/800HT Coils Supplier, Stockist & Importer
Incoloy 800/800HT Coils
Nickel Alloy 800/800HT Coils
Excellent resistance to oxidation and scaling · High strength at elevated temperatures · Good resistance to carburization · Global Industrial Supply
ASTM B409 / ASME SB409
UNS N08800 / N08810 / N08811
EN 1.4876 / 1.4958 / 1.4959
JIS NCF 800
📋 Table of Contents
HRS Ferritic · Trusted Global Supplier
What are Incoloy 800/800HT Coils?
Incoloy 800/800HT Coils are nickel-iron-chromium alloy coils designed for high-temperature strength and excellent resistance to oxidation and carburization. These coils are widely used in environments where materials must withstand prolonged exposure to elevated temperatures. Incoloy 800 offers good strength and corrosion resistance, while Incoloy 800HT provides enhanced creep resistance and stability at higher temperatures, making them suitable for critical industrial applications.
- Excellent resistance to oxidation and scaling
- High strength at elevated temperatures
- Good resistance to carburization
- Long service life in extreme environments
- Stable microstructure under thermal stress
- Suitable for continuous high-temperature operations
HighDurable
Working Mechanism
How Incoloy 800/800HT Coil Works
Incoloy 800/800HT Coils work through their balanced composition of nickel, iron, and chromium, which provides excellent resistance to oxidation and scaling. Chromium forms a protective oxide layer on the surface, preventing further corrosion when exposed to high-temperature environments. Controlled carbon, aluminum, and titanium content in Incoloy 800HT improves creep strength and structural stability.
30-35%
Nickel Content
19-23%
Chromium Content
500-750
Tensile MPa
0.5-100
Thickness (mm)
Composition Analysis
Metallurgical Characteristics of Incoloy 800/800HT Coils
Key alloying elements that contribute to the high-performance structure of Incoloy 800/800HT grades.
Ni
Nickel
Provides primary resistance to oxidation and general corrosion in various environments.
Cr
Chromium
Forms a protective oxide layer that prevents scaling and carburization.
Fe
Iron
Maintains structural stability and the fundamental alloy matrix.
C
Carbon
Enhances creep strength when present in controlled amounts for high-heat service.
Al
Aluminum
Improves high-temperature oxidation resistance and thermal durability.
Ti
Titanium
Stabilizes the alloy structure and prevents intergranular degradation.
Technical Data
Specifications for Incoloy 800/800HT Coils
ASTM B409 · ASME SB409 · UNS N08800 / N08810 / N08811 · EN 1.4876
| Specification | Details |
|---|---|
| ASTM / ASME | ASTM B409 / ASME SB409 |
| UNS | UNS N08800 / UNS N08810 / UNS N08811 |
| EN | 1.4876 / 1.4958 / 1.4959 Or X10NiCrAlTi32-20 |
| DIN | 1.4876 / 1.4958 / 1.4959 Or X10NiCrAlTi32-20 |
| ISO | ISO 6208 |
| JIS | NCF 800 |
| Product Form | Sheets / Plates / Coils |
| Thickness Range | 0.5 mm to 100 mm |
| Standard Widths | 1000, 1219, 1250, 1500, 1800, 2000, 2500, 3000, 3500 mm, etc |
| Standard Lengths | 2000, 2440, 2500, 3000, 5800, 6000 mm, etc |
| Custom Cut | Custom Width and Length Cut available as per customer requirement |
| Surface Finish | Hot Rolled (HR), Cold Rolled (CR), Annealed & Pickled (AP) |
| Supply Condition | Solution Annealed |
| Cutting Methods | Plasma, Laser, Waterjet, Oxy Propane |
| Packaging | Bundled, Wooden Plates, Bubble wraps, Customized |
Inventory
Available Stock & Product Forms
Slit Coils
Precision slitting coils, strips, and thin foils from 0.05 mm thickness.
Flat Products
Precision sheets, heavy plates, and shim sheets available in various grades.
Specialty Blanks
Circles, rings, custom-cut blanks, and chequered plates tailored to specs.
Edge Types
Mill edge, slit edge, round edge, and square edge conditions available.
Nickel (Ni)
30.0–35.0% — Crucial for oxidation and corrosion resistance.
Chromium (Cr)
19.0–23.0% — Forms the protective high-heat oxide layer.
Carbon (C)
0.05–0.10% — Higher range specifically for 800H/800HT creep strength.
Aluminum (Al)
0.15–0.60% — Enhances durability in oxidizing atmospheres.
Tensile Strength
500–750 MPa — Reliable structural integrity at intense temperatures.
Yield Strength
210–310 MPa — 0.2% offset yield for high-stress industrial applications.
Elongation
30–45 % — Excellent ductility for fabrication and break resistance.
Hardness
135–200 HB — Optimized hardness for toughness and machining.
Product Range
Types of Incoloy 800/800HT Coils
Available in multiple finishes and conditions for diverse alloy engineering needs.
Hot Rolled Incoloy 800/800HT Coils
Cold Rolled Incoloy 800/800HT Coils
Bright Annealed Coils
Slit Edge Coils
Polished Coils
Annealed & Pickled Coils
Application Sectors
Industries We Serve
Sugar Industry
Global cane and beet processing requiring thermal endurance.
Power Industry
Electricity generation and distribution systems.
Ship Building
Marine propulsion and exhaust components.
Mechanical & Plant Engineering
Industrial machinery design solutions.
Food, Beverage & Dairy
Processed food manufacturing environments.
Oil & Gas Plant
Refinery furnace units and burner assemblies.
Chemical Composition
Chemical Details of Incoloy 800/800HT Coils
Detailed percentage composition of Incoloy 800/800HT series alloys.
| Element | Composition (%) |
|---|---|
| Nickel (Ni) | 30.0 – 35.0 |
| Chromium (Cr) | 19.0 – 23.0 |
| Iron (Fe) | Balance (typically 39.5 min) |
| Carbon (C) | 0.05 – 0.10 (800H/800HT higher range) |
| Aluminum (Al) | 0.15 – 0.60 |
| Titanium (Ti) | 0.15 – 0.60 |
| Manganese (Mn) | ≤ 1.50 |
| Silicon (Si) | ≤ 1.00 |
| Copper (Cu) | ≤ 0.75 |
| Sulfur (S) | ≤ 0.015 |
Performance Data
Mechanical Properties of Incoloy 800/800HT Coils
500–750
Tensile Strength
MPa — Minimum Ultimate Tensile Strength for Incoloy 800/800HT
210–310
Yield Strength
MPa — 0.2% Offset Yield Strength for structural reliability
30–45 %
Elongation
High ductility at break for specialized industrial forming
135–200 HB
Hardness
Brinell hardness range (140–210 HV Vickers)
7.94–7.97
Density
g/cm³ — Specific gravity for precise weight calculations
195–205 GPa
Elastic Modulus
Structural stiffness with 75–80 GPa Shear Modulus
Cost Information
Price List for Incoloy 800/800HT Coils
Price Factors
What affects the Incoloy 800/800HT price?
- Fluctuations in nickel and chromium raw material costs
- Coil thickness, dimensions, and weight requirements
- Surface finish requirements (Bright Annealed, Polished)
- Total order quantity and economies of scale
- Current global market demand and supply availability
Get Pricing Today
Get A Quote!
Competitive rates · High quality · Global delivery
📧 [email protected]
International Standards
Equivalent Grades for Incoloy 800/800HT Coils
Cross-reference table for international designations of Incoloy 800/800H/800HT.
| Standard | Equivalent Grade / Designation |
|---|---|
| UNS | N08800 (800) / N08810 (800H) / N08811 (800HT) |
| ASTM | B409 (sheet/coil) / B408 (bar) / B407 (pipe) / B564 (forgings) |
| ASME | SB409 / SB408 / SB407 / SB564 |
| AMS / SAE | AMS 5871 (sheet/strip) / AMS 5766 (bar/forging) |
| ISO | ISO 6208 / ISO 9724 / ISO 9723 |
| EN (European) | X10NiCrAlTi32-20 |
| DIN / Werkstoff | 1.4876 (800) / 1.4958 (800H) / 1.4959 (800HT) |
| JIS (Japan) | NCF 800 |
| BS (British) | NA15 |
| AFNOR (France) | Z8NC32-21 |
| GOST (Russia) | 08X18H32T (approx. equivalent) |
| NACE | MR0175 / ISO 15156 compliant grades |
| API | 6A (high-temperature service) |
| MIL (Military) | MIL-N-08800 series |
📦
Ready Stock Availability
- Flat Products: Precision sheets, heavy plates, shim sheets
- Coils & Strips: Slitting coils, perforated coils, thin foils (from 0.05 mm)
- Speciality Forms: Circles, rings, custom-cut blanks, chequered (tread) plates
- Edge Conditions: Mill edge, slit edge, round edge, square edge
🏭
Quality & Logistics
- Testing: PMI, Ultrasonic Testing (UT), Radiography (RT), corrosion testing
- Certification: EN 10204 3.1 / 3.2, NACE compliance (on request)
- Global Logistics: Supplying USA, UAE, Saudi Arabia, Singapore, Indonesia, Europe
- Export Grade: ISPM-15 fumigated wooden crates, shrink-wrapped & moisture-protected
Use Cases
Applications of Incoloy 800/800HT Coils
✈️ Aerospace
Used in aerospace heat exchangers and exhaust systems for thermal stability.
⛽ Oil & Gas
Used in processing equipment and pipelines for reliable safe operations.
🌾 Fertilizer Industry
Handling ammonia and aggressive chemicals during high-temp processing.
⚡ Electric & EV
Thermal stability for electrical systems and advanced EV energy storage.
🏗️ Construction
Structural components exposed to high temperatures and corrosive environments.
🧪 Chemical Processing
Applied in reactors and exchangers where resistance to oxidation is critical.
🚗 Automotive
Used in exhaust systems and high-temp components for demanding conditions.
💊 Pharmaceuticals
Ensuring hygiene standards and product purity in sterile processing equipment.
Why HRS Ferritic
Why Choose HRS Ferritic for Incoloy 800/800HT Coils?
HRS Ferritic is a globally recognized leader in the metal industry, known as a reliable Incoloy 800/800HT Coils Supplier, Stockist, and Importer, offering premium-quality alloy products sourced from valuable and certified manufacturers.
Leading Incoloy 800/800HT Coils Supplier
Reliable Coils Stockist with wide inventory
Trusted Importer sourcing certified materials
Competitive pricing for industrial scale
Fast delivery and global logistics reach
Full material traceability & documentation
Expert technical support for alloy selection
Precision sourcing from global manufacturers
🇮🇳
Cities We Supply In India
New Delhi · Ahmedabad · Jaipur · Surat · Salem · Gandhinagar · Varanasi · Haldia ·
Bhiwandi · Tiruppur · Jamnagar · Thiruvananthapuram · Rajahmundry · Visakhapatnam · Bhubaneswar ·
Vijaywada · Rajkot · Bharuch · Coimbatore · Nagpur · Raipur · Cochin · Ludhiana · Panipat · Durgapur ·
Agra · Indore · Kuala Lumpur · Al Jubail · Pimpri-Chinchwad · Sharjah · Karachi · Chandigarh · Bogota · Muscat · Madrid · Tehran · Granada · Jakarta · Los Angeles · Rio de Janeiro · Melbourne · Cairo · New York · Busan · Milan · Montreal · Singapore · Sydney · Dubai · Lagos · Gurgaon · Port-of-Spain · Hong Kong · Navi Mumbai · Secunderabad · Bangkok · Aberdeen · Bhopal · Atyrau · Caracas · Jamshedpur · Thane · Faridabad · Ahvaz · Ahmedabad · Hanoi · Bengaluru · Dallas · Moscow · Surat · Riyadh · Rajkot · Al Khobar · Hyderabad · Haryana · Ernakulam · Gimhae-si · Algiers · Thiruvananthapuram · Brisbane · Calgary · Mumbai · Chennai · Courbevoie · Toronto · Vung Tau · Ankara · Doha · Nagpur · Howrah · Ranchi · Perth · Noida · Houston · Kolkata · Chiyoda · Mexico City · Edmonton. Geoje-si · Abu Dhabi · Santiago · New Delhi · Colombo · Ludhiana · Lahore · Coimbatore · Ho Chi Minh City · Manama · Ulsan · London · Visakhapatnam · Jaipur · Kuwait City · Seoul · Istanbul · Pune · Baroda · Kanpur · La Victoria · Jeddah · Dammam · Petaling Jaya · Nashik · Vadodara ·jamnagar ·hazira · jubail industrial city · Ajman · Capetown · San Francisco · sao paulo · Barcelona · Ahmedi · Muscat · Madrid · Birmingham · Johannesburg.
🌍
Countries We Export To
Saudi Arabia · Qatar · Canada · Sri Lanka · Iran · Nigeria · Bangladesh · Oman · UAE ·
Turkey · Kuwait · Venezuela · Africa · Singapore · Netherlands · United Kingdom · Mexico · Malaysia ·
United States · Australia · Japan Saudi Arabia · Iran · Iraq · UAE · Qatar · Bahrain · Oman · Kuwait · Turkey · Yemen · Syria · Jordan · Cyprus · Nigeria · Algeria · Angola · South Africa · Libya · Egypt · Sudan · Equatorial Guinea · The Republic Of Congo · Gabon · USA · Canada · Mexico · Panama · Costa Rica · Puerto Rica · Trinidad And Tobago · Jamaica · Bahamas · Denmark · Russia · Norway · Germany · France · Italy · Uk · Spain · Ukraine · Netherland · Belgium · Greece · Czech Republic · Portugal · Hungary · Albania · Austria · Switzerland · Slovakia · Finland · Ireland · Croatia · Slovenia · Malta · India · Singapore · Malaysia · Indonesia · Thailand · Vietnam · South Korea · Japan · Sri Lanka · Maldives · Bangladesh · Myanmar · Taiwan · Cambodia · Argentina · Bolivia · Brazil · Chile · Venezuela · Colombia · Ecuador · Guyana · Paraguay · Uruguay · New Zealand · Romania · Puerto Rico · Nepal · Kenya · Afghanistan · Lithuania · Belarus · Zimbabwe · Israel · Azerbaijan · Poland · Australia · Morocco · Philippines.
Support
Frequently Asked Questions
Quick answers to common queries about Incoloy 800/800HT Coils.
Larger sizes increase material usage and handling costs, raising the overall price when purchasing from an Incoloy 800/800HT Coils Supplier for industrial applications.
Thicker coils require more raw material and processing, significantly increasing pricing when sourced from an Incoloy 800/800HT Coils Stockist or manufacturer.
Advanced finishes like bright annealed or polished increase processing requirements, raising final pricing from an Incoloy 800/800HT Coils Importer due to improved surface quality.
Yes, fluctuations in nickel, chromium, and alloy elements directly impact pricing offered by any Incoloy 800/800HT Coils Supplier in the global market.
Custom sizes increase production complexity and costs due to additional processing, making them more expensive when sourced from an Incoloy 800/800HT Coils Stockist.
Bulk orders reduce per-unit cost due to economies of scale, making purchases from an Incoloy 800/800HT Coils Importer more cost-effective for large industrial requirements.
These coils are ideal for high-temperature applications like furnaces and heat exchangers, offering durability and oxidation resistance from a trusted Incoloy 800/800HT Coils Supplier.
