Hastelloy C276 Plate Supplier, Stockist & Importer
Hastelloy C276 Stainless Steel Plates
Alloy C276 Plates
HRS Ferritic is a renowned Hastelloy C276 Plate Supplier, Stockist, and Importer, offering top-grade alloy plates sourced from certified global manufacturers.
ASTM B575 / ASME SB575
UNS N10276
EN 2.4819 / NiMo16Cr15W
NW 0276
📋 Table of Contents
HRS Ferritic · Trusted Global Supplier
What is Hastelloy C276 Plate?
Hastelloy C276 Plate is a nickel-molybdenum-chromium alloy known for its exceptional resistance to corrosion in both oxidizing and reducing environments. It performs extremely well in harsh chemical conditions, including exposure to acids, chlorides, and seawater. Hastelloy C276 Plates are widely used in industries where high resistance to pitting, crevice corrosion, and stress corrosion cracking is essential.
- Outstanding resistance to corrosion in harsh environments
- Excellent performance in both oxidizing and reducing conditions
- High resistance to pitting and crevice corrosion
- Superior mechanical strength and durability
- Long service life with minimal maintenance
- Suitable for extreme chemical processing applications
- Reliable under high temperature and pressure
HighCorrosion Resistant
Working Mechanism
How Hastelloy C276 Plate Works
Hastelloy C276 Plate functions by forming a highly stable and protective oxide layer on its surface when exposed to aggressive chemical environments. The presence of chromium enhances oxidation resistance, while molybdenum improves resistance to localized corrosion such as pitting and crevice corrosion.
14-16%
Chromium Content
57%
Nickel Base
690
Tensile MPa
0.5-100
Thickness (mm)
Composition Analysis
Metallurgical Characteristics of Hastelloy C276 Plate
Key alloying elements that contribute to the high-performance corrosion-resistant structure of Alloy C276.
Ni
Nickel
Primary base element providing overall corrosion resistance and structural stability.
Mo
Molybdenum
Enhances resistance to pitting and crevice corrosion, especially in reducing environments.
Cr
Chromium
Improves resistance to oxidizing media and forms a protective oxide layer.
W
Tungsten
Increases resistance to localized corrosion and improves durability in harsh conditions.
Fe
Iron
Present as a secondary element, it contributes to strength and cost balance.
Co
Cobalt
Minor addition that supports high-temperature strength.
Mn
Manganese
Acts as a deoxidizer during alloy production.
C
Carbon
Controlled at low levels to prevent carbide precipitation and maintain corrosion resistance.
Technical Data
Specifications for Hastelloy C276 Plate
ASTM B575 · ASME SB575 · UNS N10276 · EN 2.4819
| Specification | Details |
|---|---|
| ASTM / ASME | ASTM B575 / ASME SB575 (Plate, Sheet, and Strip) |
| UNS | UNS N10276 |
| EN | 2.4819 / NiMo16Cr15W |
| DIN | 2.4819 / NiMo16Cr15W |
| ISO | NW 0276 |
| JIS | NW 0276 |
| Product Form | Sheets / Plates |
| Thickness Range | 0.5 mm to 100 mm |
| Standard Widths | 1000, 1219, 1250, 1500, 1800, 2000, 2500, 3000, 3500 mm, etc |
| Standard Lengths | 2000, 2440, 2500, 3000, 5800, 6000 mm, etc |
| Surface Finish | Hot Rolled (HR), Cold Rolled (CR), Annealed & Pickled (AP) |
| Supply Condition | Solution Annealed |
| Cutting Methods | Plasma, Laser, Waterjet, Oxy Propane |
| Packaging | Bundled, Wooden Plates, Bubble wraps, Customized |
Inventory
Available Stock & Product Forms
Flat Plates
Precision sheets, heavy plates, and shim sheets available in various grades.
Coils & Strips
Slitting coils, perforated coils, and thin foils from 0.05 mm thickness.
Specialty Blanks
Circles, rings, and custom-cut blanks tailored to your specifications.
Edge Types
Mill edge, slit edge, round edge, and square edge conditions available.
Molybdenum (Mo)
15.0–17.0% — Enhances resistance to pitting and crevice corrosion.
Nickel (Ni)
~57% Base — Provides structural stability and general resistance.
Chromium (Cr)
14.5–16.5% — Crucial for oxidation resistance in aggressive media.
Tungsten (W)
3.0–4.5% — Improves durability and localized corrosion resistance.
Tensile Strength
690 MPa — Extreme strength for high-stress industrial applications.
Yield Strength
283 MPa — Solid structural integrity for pressurized components.
Elongation
40% — Excellent ductility for processing and complex fabrication.
Hardness
85 HRB — Balanced hardness ensuring toughness and workability.
Product Range
Types of Hastelloy C276 Plate
Available in multiple finishes and conditions for diverse engineering needs.
Hastelloy C276 Hot Rolled Plate
Hastelloy C276 Cold Rolled Plate
Hastelloy C276 Polished Plate
Hastelloy C276 Industrial Plate
Custom Cut Hastelloy C276 Plate
Hastelloy C276 Annealed & Pickled Plate
Application Sectors
Industries We Serve
Sugar Industry
Global cane and beet processing requiring thermal endurance.
Power Industry
Electricity generation and distribution systems.
Ship Building
Marine propulsion and exhaust components.
Mechanical & Plant Engineering
Industrial machinery design solutions.
Food, Beverage & Dairy
Processed food manufacturing environments.
Oil & Gas Plant
Refinery furnace units and burner assemblies.
Chemical Composition
Chemical Details of Hastelloy C276 Plate
Typical chemical balance for UNS N10276 alloy.
| Element | Composition (%) |
|---|---|
| Nickel (Ni) | 57% (Base) |
| Molybdenum (Mo) | 15.0–17.0 |
| Chromium (Cr) | 14.5–16.5 |
| Iron (Fe) | 4.0–7.0 |
| Tungsten (W) | 3.0–4.5 |
| Cobalt (Co) | ≤ 2.5 |
| Manganese (Mn) | ≤ 1.00 |
| Vanadium (V) | ≤ 0.35 |
| Carbon (C) | ≤ 0.01 |
Performance Data
Mechanical Properties of Hastelloy C276 Stainless Steel Plate
690
Tensile Strength
MPa — Minimum Ultimate Tensile Strength for Alloy C276
283
Yield Strength
MPa — 0.2% Offset Yield Strength for high-pressure reliability
40%
Elongation
High ductility for forming and fabrication efficiency
85 HRB
Hardness
Typical Rockwell B Hardness for industrial plates
205 GPa
Elastic Modulus
Structural stiffness for heavy industrial loads
8.89 g/cm³
Density
Material mass density for weight calculation
Cost Information
Price List for Hastelloy C276 Plate
Price Factors
What affects the Hastelloy C276 price?
- Fluctuations in raw materials like nickel and molybdenum
- Plate thickness and custom dimensions
- Surface finish and customization requirements
- Market demand and global supply conditions
- Import duties and transportation costs
- Custom cutting and fabrication readiness
Get Pricing Today
Get A Quote!
Competitive rates · High quality · Global delivery
📧 [email protected]
International Standards
Equivalent Grades for Hastelloy C276 Plate
Cross-reference table for international designations of C276 plates.
| Standard / System | Grade / Designation |
|---|---|
| UNS | N10276 |
| ASTM / ASME | B575 / SB575 |
| DIN / Werkstoff | 2.4819 |
| EN (European) | 2.4819 / NiMo16Cr15W |
| JIS (Japan) | NW 0276 |
| GOST (Russia) | ХН65МВУ (KhN65MVU) |
| BS (British Standard) | NA 45 |
| AFNOR (France) | NC17D |
📦
Ready Stock Availability
- Flat Products: Precision sheets, heavy plates, shim sheets
- Coils & Strips: Slitting coils, perforated coils, thin foils from 0.05 mm
- Speciality Forms: Circles, rings, custom-cut blanks, chequered (tread) plates
- Edge Conditions: Mill edge, slit edge, round edge, square edge
🏭
Quality & Logistics
- Testing: PMI, Ultrasonic (UT), Radiography (RT), corrosion testing
- Certification: EN 10204 3.1 / 3.2, NACE compliance on request
- Global Logistics: Supplying USA, UAE, Saudi Arabia, Singapore, Indonesia, Europe
- Export Grade: ISPM-15 fumigated wooden crates, moisture-protected packaging
Use Cases
Applications of Hastelloy C276 Plate
✈️ Aerospace
Used in aerospace components where high resistance to extreme temperatures and corrosion is required.
⛽ Oil & Gas
Widely used in pipelines, refineries, and offshore equipment exposed to corrosive environments.
🌾 Fertilizer Industry
Ideal for handling aggressive chemicals used in fertilizer production processes.
⚡ Electric & EV
Used in battery systems and electrical components requiring corrosion resistance and durability.
🏗️ Construction
Applied in structures exposed to harsh environmental conditions for long-term performance.
🧪 Chemical Processing
Extensively used in reactors, heat exchangers, and storage tanks handling highly corrosive chemicals.
🚗 Automotive
Used in exhaust systems and components exposed to high temperatures and corrosive gases.
💊 Pharmaceuticals
Ensures contamination-free and corrosion-resistant processing environments.
Why HRS Ferritic
Why Choose HRS Ferritic for Hastelloy C276 Plates?
HRS Ferritic is a leading Hastelloy C276 Plate Supplier and Stockist, delivering high-performance alloy products. Sourced from certified global manufacturers, we ensure premium quality, competitive pricing, and global delivery for critical industrial projects.
Leading Hastelloy C276 Plate Supplier & Stockist
Premium quality materials from certified global mills
Wide range of sizes and custom specifications
Competitive pricing with bulk availability
Quick delivery and global export capability
EN 10204 3.1 / 3.2 quality documentation
Dedicated expert technical support
Reliable Hastelloy C276 Plate Importer services
🇮🇳
Cities We Supply In India
New Delhi · Ahmedabad · Jaipur · Surat · Salem · Gandhinagar · Varanasi · Haldia ·
Bhiwandi · Tiruppur · Jamnagar · Thiruvananthapuram · Rajahmundry · Visakhapatnam · Bhubaneswar ·
Vijaywada · Rajkot · Bharuch · Coimbatore · Nagpur · Raipur · Cochin · Ludhiana · Panipat · Durgapur ·
Agra · Indore · Kuala Lumpur · Al Jubail · Pimpri-Chinchwad · Sharjah · Karachi · Chandigarh · Bogota · Muscat · Madrid · Tehran · Granada · Jakarta · Los Angeles · Rio de Janeiro · Melbourne · Cairo · New York · Busan · Milan · Montreal · Singapore · Sydney · Dubai · Lagos · Gurgaon · Port-of-Spain · Hong Kong · Navi Mumbai · Secunderabad · Bangkok · Aberdeen · Bhopal · Atyrau · Caracas · Jamshedpur · Thane · Faridabad · Ahvaz · Ahmedabad · Hanoi · Bengaluru · Dallas · Moscow · Surat · Riyadh · Rajkot · Al Khobar · Hyderabad · Haryana · Ernakulam · Gimhae-si · Algiers · Thiruvananthapuram · Brisbane · Calgary · Mumbai · Chennai · Courbevoie · Toronto · Vung Tau · Ankara · Doha · Nagpur · Howrah · Ranchi · Perth · Noida · Houston · Kolkata · Chiyoda · Mexico City · Edmonton. Geoje-si · Abu Dhabi · Santiago · New Delhi · Colombo · Ludhiana · Lahore · Coimbatore · Ho Chi Minh City · Manama · Ulsan · London · Visakhapatnam · Jaipur · Kuwait City · Seoul · Istanbul · Pune · Baroda · Kanpur · La Victoria · Jeddah · Dammam · Petaling Jaya · Nashik · Vadodara ·jamnagar ·hazira · jubail industrial city · Ajman · Capetown · San Francisco · sao paulo · Barcelona · Ahmedi · Muscat · Madrid · Birmingham · Johannesburg.
🌍
Countries We Export To
Saudi Arabia · Qatar · Canada · Sri Lanka · Iran · Nigeria · Bangladesh · Oman · UAE ·
Turkey · Kuwait · Venezuela · Africa · Singapore · Netherlands · United Kingdom · Mexico · Malaysia ·
United States · Australia · Japan Saudi Arabia · Iran · Iraq · UAE · Qatar · Bahrain · Oman · Kuwait · Turkey · Yemen · Syria · Jordan · Cyprus · Nigeria · Algeria · Angola · South Africa · Libya · Egypt · Sudan · Equatorial Guinea · The Republic Of Congo · Gabon · USA · Canada · Mexico · Panama · Costa Rica · Puerto Rica · Trinidad And Tobago · Jamaica · Bahamas · Denmark · Russia · Norway · Germany · France · Italy · Uk · Spain · Ukraine · Netherland · Belgium · Greece · Czech Republic · Portugal · Hungary · Albania · Austria · Switzerland · Slovakia · Finland · Ireland · Croatia · Slovenia · Malta · India · Singapore · Malaysia · Indonesia · Thailand · Vietnam · South Korea · Japan · Sri Lanka · Maldives · Bangladesh · Myanmar · Taiwan · Cambodia · Argentina · Bolivia · Brazil · Chile · Venezuela · Colombia · Ecuador · Guyana · Paraguay · Uruguay · New Zealand · Romania · Puerto Rico · Nepal · Kenya · Afghanistan · Lithuania · Belarus · Zimbabwe · Israel · Azerbaijan · Poland · Australia · Morocco · Philippines.
Support
Frequently Asked Questions
Quick answers to common queries about Hastelloy C276 Plates.
When you choose larger Hastelloy C276 plate sizes, the price naturally increases because more raw material is used and production handling becomes more complex.
Thicker Hastelloy C276 plates cost more since they require higher alloy content, increased rolling effort, and longer manufacturing time.
Yes, opting for polished or precision finishes on Hastelloy C276 plates adds to the cost due to extra processing and quality checks.
Hastelloy C276 plate prices often fluctuate with global nickel, molybdenum, and chromium rates, making raw material cost a key pricing factor.
Custom Hastelloy C276 plates usually come at a higher price because of additional cutting, material wastage, and lower production efficiency.
Yes, Hastelloy C276 plates used in chemical processing, offshore, or high-corrosion environments tend to cost more due to stricter quality and certification requirements.
Heat-treated Hastelloy C276 plates are priced higher because processes like solution annealing require controlled conditions and extra energy.
Hastelloy C276 plates with certifications like NACE or third-party inspection cost more due to added testing, verification, and documentation.
